Bluetooth OBD2 scanner for Android & iOS devices.
Reads & clears engine fault codes and live data.
Low-power sleep mode prevents battery drain.
Compact, reliable tool for daily vehicle diagnostics.
Vgate iCar Pro Car Diagnostic Tool is a professional-grade OBDII diagnostic scan tool designed to turn your smartphone, tablet, or PC into a sophisticated automotive diagnostic system. It is widely regarded for its "fit and forget" design, compact size, and broad compatibility with third-party apps.
Comprehensive Diagnostics: Read and clear Diagnostic Trouble Codes (DTCs), including both generic and manufacturer-specific codes (over 3,000 definitions in the database).3 It effectively resets the "Check Engine" light (MIL).
Real-Time Data Monitoring: View live engine sensor data (PIDs) such as:
Engine RPM and Vehicle Speed
Coolant Temperature and Intake Air Temperature
Fuel System Status and Fuel Pressure
Short/Long Term Fuel Trim
Mass Air Flow and Absolute Throttle Position
"Fit and Forget" Battery Saver:10 Features a unique Auto Sleep and Auto Wake-up function.11 It enters a low-power standby mode (<3mA) after 30 minutes of engine inactivity and wakes up instantly when the engine starts or doors unlock, allowing you to leave it plugged in permanently without draining the battery.
Fast & Stable Performance: Utilizes high-speed ARM chips for stable wireless connections and fast data transfer (up to 30 PIDs per second).
| Feature | Details |
| Connection Options | Bluetooth 4.0 (BLE), Bluetooth 3.0, or Wi-Fi versions available |
| Hardware Version | ELM327 V2.3 (latest stable version) |
| Operating Voltage | 11.5V – 15V |
| Operating Temp | -40°C to +85°C |
| Protocols Supported | All 5 OBDII protocols: CAN, KWP2000, ISO9141-2, J1850 VPW, J1850 PWM |
| Vehicle Compatibility | 12V Gasoline (1996+ US, 2001+ EU) and Diesel (2003/2004+ EU) |
The device does not have a dedicated app but works with almost all popular third-party OBDII software:
iOS: Car Scanner ELM OBD2, OBD Auto Doctor, OBD Fusion, BimmerCode.
Android: Torque Pro/Lite, DashCommand, Forscan (for Ford/Mazda), JScan (for Jeep/Dodge).
Windows: ScanMaster-ELM.
Vgate iCar Pro OBDII Adapter
User Manual
12V Only: Not compatible with 24V heavy-duty vehicles (trucks/tractors).
System Access: Primarily accesses the Engine and Transmission (Powertrain).18 Its ability to read ABS, Airbag (SRS), or TPMS codes depends on the specific software/app used (e.g., BimmerCode for BMWs or Forscan for Fords).
