Autel Scanner MaxiCOM MK808S stands out for superior hardware and cost-effective professional features. It comes equipped with faster CPU ROCKCHIP RK3566, improved OS Android 11, larger 4GB+64GB, 5G Wi-Fi, and newly added Wi-Fi Print.
1) Oil Reset: Reset the new calculation of Engine Oil Life System for an accurate reading of the next oil change.
2) EPB Reset: Reset the calipers, brake discs or pads after the electronic parking brake system is repaired.
3) BMS Reset: Reset after replacing the battery to clear the low battery fault information of the original battery and protect the new battery.
4) DPF Regeneration: Clear PM from the DPF filter through oxidation or combustion to stabilize the filter performance.
5) Injector Coding: Code a new injector to better identify injectors to accurately control fuel injection.
6) ABS Bleeding: Perform to bleed the brake system to restore ABS braking sensitivity and obtain a firm brake pedal .
7) SAS Adjustment: Clear the fault steering angle sensor memories, perform reset steering angle sensor, and turn off steering wheel warning light.
8) Throttle Relearn: Reset the throttle actuators to accurately regulate throttle (or idle engine) operations, helps keep your idling and acceleration smooth.
9) Headlight Matching: initialize the adaptive headlight system
Works well for 150+ car brands, 10000+ American, European, and Asian car models,
| Operating System | AndroidTM 11 |
| Processor | Rockchip RK3566 Quad Core Processor 4x1.8GHz(A55) |
| Memory | 64GB |
| Display | 7-inch LCD capacitive touchscreen with 1024x600 resolution |
| Connectivity | Mini USB 2.0 |
| USB 2.0 | |
| Wi-Fi | |
| Micro SD card (supports up to 64GB) | |
| Sensors | Ambient light sensor for brightness auto adjust |
| Audio Input/Output | Input: N/A |
| Output: Beep | |
| Power and Battery | 3.7 V/3200 mAh lithium-polymer battery |
| Charges via 5 VDC power supply | |
| Tested Battery Life | Around 4.5 hours of continuous use |
| Battery Charging Input | 5 V/1.5 A |
| Power Consumption | 500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V |
| Operating Temp. | 0 to 55°C(14 to 131°F) |
| Storage Temp. | -20 to 60°C (-4 to 140°F) |
| Operating Humidity | 5% - 95% non-condensing |
| Supported Automotive Protocols | ISO9141-2, ISO14230-2,ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898(Highspeed, Middlespeed, Lowspeed and Singlewire CAN, fault-tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6 |
